Rotary Bottle Unscrambler

Rotary Bottle Unscrambler

Rotary bottle unscrambler is mainly used for automatic bottle separation and automatic transmission of round bottles and square bottles, such as the conveyor belt connected to labelling machine, filling machine and capping machine, automatic bottle feeding to improve efficiency; it can be used in the middle connection of assembly line as a buffer platform to shorten the length of conveyor belt. The rotary bottle unscrambler put messy bottles on round plate into the conveyor belt of the next process orderly through rotation of round plate, and has a buffer action. It is suitable for automatic bottle unscramble and transportation of plastic bottles in food, daily chemical, medicine, beverage and other industries.

,

1. Product Features:

(1)  Bottle unscrambler is suitable for free adjustment of bottle diameter, compatible with peeling bottles and plastic bottles, bottle conveying speed of 30~400 bottles/min (related to bottle size specifications), speed can be steplessly adjusted, convenient to arrange production.

(2) Classification

  • According to bottle material: glass bottle unscrambler, plastic bottle unscrambler, PET bottle unscrambler.
  • According to bottle shape: round bottle unscrambler, square bottle unscrambler, complicated-shape bottle unscrambler.

(3) Technical parameter: (The following are standard models. For other special requirements and functions, it can be customized.)

  • Applicable product diameter (for round bottles): φ20mm~φ100mm
  • Height: 16mm~200mm
  • Weight: about 120kg
  • Frequency: 50Hz
  • Voltage: 220V
  • Power: 120W
  • Overall Dimension: (LxWxH) 990mm×900mm×1040mm

2.  Function Features:

  •  It is a mechatronic equipment with easy operation, simple maintenance and reliable operation.
  • The rack and platform are made of stainless steel with beautiful appearance and meet the requirements of GMP.
  • It is suitable for automatic transmission of round bottles and square bottles, such as conveyor belt connected to labelling machine, filling machine and capping machine, automatic bottle feeding, which can improve efficiency; it can be used in the middle connection of assembly line as a buffer platform to shorten the length of conveyor belt.
  •  The range of applicable bottles can be adjusted freely, the conveying speed of bottles is 30~400 bottles/min, and the speed can be adjusted steplessly, which is convenient for production.
  • To reduce labor intensity and improve efficiency.
